EV battery-pack thermal simulation

A thermal simulation workbench for comparing EV battery-pack layouts, cooling strategies, operating loads, and cell-temperature uniformity.

  • Nuxt
  • Vue
  • FastAPI
  • PostgreSQL
  • Python
  • NumPy
  • SciPy
  • Docker

Project definition

Problem statement

Battery cells generate heat during charging and discharge, and pack geometry, contact resistance, ambient conditions, and cooling flow affect peak temperature and temperature difference between cells.

The engineering problem is to construct a computationally manageable thermal model, verify its numerical behaviour, and compare design choices without presenting the result as a certified pack design.

Project objectives

  • Model selected cell arrangement, material layers, thermal properties, contacts, and cooling boundaries.
  • Convert prepared current or drive-cycle profiles into documented cell heat-generation inputs.
  • Calculate transient cell and pack temperatures under air, cold-plate, or simplified cooling cases.
  • Compare peak temperature, temperature uniformity, cooling energy proxy, and thermal response.
  • Verify the solver with analytical, mesh, time-step, and energy-balance checks.

System design

System modules

01

Pack configurator

Defines cells, spacing, materials, interfaces, thermal properties, sensors, and boundary conditions.

02

Load and heat model

Transforms prepared current, resistance, entropy, and state assumptions into heat-generation profiles.

03

Thermal solver

Solves the selected lumped or discretised transient heat equations under recorded numerical settings.

04

Cooling model

Applies convective, cold-plate, or simplified channel boundary conditions and cooling effort estimates.

05

Design dashboard

Shows temperature fields, cell traces, hotspots, gradients, energy checks, and parameter comparisons.

Methodology

System workflow

  1. 01
    Configure pack

    The student selects a prepared geometry, cell data, materials, and cooling arrangement.

  2. 02
    Load duty cycle

    A current profile and initial and ambient conditions produce the heat-input series.

  3. 03
    Run baseline

    The solver calculates transient pack and cell temperatures and energy balance.

  4. 04
    Change design

    Spacing, interface, flow, plate, or control parameters are varied under the same duty cycle.

  5. 05
    Verify and compare

    Numerical checks and thermal results identify the documented design tradeoff.

Demonstration scenario

A prepared battery module follows an urban drive cycle under natural convection. The baseline develops a central hotspot. A cold-plate case and a changed cell spacing are simulated with the same load, and the dashboard compares peak temperature, uniformity, cooling proxy, and numerical energy balance.

Engineering

Technical architecture

Web application
Nuxt and Vue for pack setup, duty-cycle charts, temperature maps, cell traces, and comparisons.
Simulation API
FastAPI for models, solver jobs, parameter sweeps, validation cases, results, and exports.
Data layer
PostgreSQL for pack versions, materials, profiles, solver settings, runs, and summary metrics.
Thermal engine
Python, NumPy, and SciPy for lumped or finite-difference energy equations, boundary conditions, and integration.
Verification
Analytical thermal cases, energy conservation, grid and time-step sensitivity, and prepared reference curves.

Testing

Evaluation

Evaluation measures

  • Peak cell temperature and maximum cell-to-cell temperature difference
  • Energy-balance residual and numerical stability
  • Agreement with analytical and prepared reference cases
  • Mesh or node and time-step independence
  • Sensitivity to heat generation, material, contact, ambient, and cooling assumptions
  • Simulation time across pack sizes, time steps, and parameter sweeps

System boundaries

  • The workbench uses simplified thermal and heat-generation models under documented assumptions.
  • It does not model cell electrochemistry, abuse, propagation, crash, sealing, or complete vehicle integration.
  • Results require experimental validation before physical design decisions.
  • The project is not a battery safety certification or a controller for a real pack.

Included

  1. 01Battery geometry, material, load, and cooling interface
  2. 02Thermal solver, parameter-sweep, and validation modules
  3. 03Temperature field, hotspot, uniformity, and energy dashboards
  4. 04Prepared pack configurations, drive cycles, and simulation results
  5. 05Complete source code in a private GitHub repository
  6. 06Complete project documentation with synopsis, abstract, methodology, thermal-model diagrams, simulation results, screenshots, and conclusion
  7. 07Setup and usage guide
